Chicago Pneumatic CP2190 Pneumatic Concrete Vibrator
Overview
Chicago Pneumatic CP2190 is an air-driven concrete vibrator for consolidating low-slump concrete in columns, footings, slabs and walls. The manufacturer lists a 63.5 mm head and a vibration rate of 12,000 VPM.
Features & Applications
- Variable-speed throttle
- In-line lubricator
- Auxiliary air hose
- Locked motor end plates
CP2190 Part Numbers
Chicago Pneumatic CP2190 Pneumatic Concrete Vibrator
CP 2190 · Part No. T019308
CP 2190
Match the model, chuck and complete-tool part number. Compare the configurations below when requesting a quote.
Safety & operating manual (PDF)
Datasheet: T019308. Confirm weight, inlet and air requirements for your tool.
Choose Your Complete Tool
Match the model, chuck and complete-tool part number. Add the configuration you need to your quote list.
| Model | Configuration | Part Number | Quote |
|---|---|---|---|
| CP 2190 | CP 2190 | T019308 |
Technical Specs
| Specification | CP 2190T019308 |
|---|---|
| Length (mm) | 3000 |
| Length measurement basis | Without auxiliary hose |
| Vibrator head length (mm) | 350 |
| Vibrator head diameter (mm) | 63.5 |
| Vibrator head diameter (in) | 2.5 |
| Vibration rate (VPM) | 12000 |
| Radius of influence (mm) | 380–405 |
| Air consumption (L/s at 6 bar) | 31 |
| Air consumption reference pressure (bar) | 6 |
| Concrete consolidation capacity (m³/h) | 30 |
