Chicago Pneumatic
CP 0077 Pump
The CP 0077 sludge pump easily handles water containing 15% solids and particles up to 1' (25 mm) in size. It is suitable for pumping seawater and certain corrosive chemicals.
- Operates on venturi/ejector principle - no motor or diaphragm to wear out
- Exhaust muffler - reduces sound level
Complete tool: CP 0077Tool part # T024005
Sludge Pump
Your BEST price is just a call away.
Adds the complete tool shown above—not an individual replacement part. Add more tools to build one quote request, then review your quote list.
1-800-241-9669
Need help with a model or part? Talk to Mining Auger & Tool Works.
Technical Specs
| Description | CP 0077 Sludge Pump |
|---|---|
| Part number | T024005 |
| Weight | 152 lb |
| Water Outlet | 2-1/2" |
| Max. suction lift | 0 ft |
| Air Consumption | 85 cfm |
| Air Inlet | 3/4" NPT |
| Performance | 90-36 gal/min @ 136 ft |
| Water Inlet | 2-1/2" |
| Dimensions | 23 x 17-3/4" |
| Max. Solids Size | 1" |
| Comments | Max. solid content 15% |
| Max Head | 174 ft |
Complete tool configurations
Match the model, shank and part number. These are complete tools, not replacement parts.
| Model | Shank / Details | Part Number | Quote |
|---|---|---|---|
| CP 0077 | Sludge Pump | T024005 |
