American Pneumatic
133 PG Handle Rivet Buster
Overview
APT 133-PG Outside Trigger, 8” Stroke, Demolition Hammer.
It is the same Hammer as the APT133-D Except for the Handle Configuration.
The 133 is an Extremely Powerful Handheld Hammer producing nearly as much Breaking Energy as a 60lb Hammer.
This tool is Excellent for all positions of Demolition Hammering including Horizontal and Overhead work. Because of its light weight and ease of handling it is frequently used on Parking Ramps, Bridge Decks, Road Work, Cleaning Concrete Ready Mix Trucks and all around concrete breaking. Additionally, with the correct accessory tools it is used for Cutting Rivets, Removing Rivets Driving Pins and more.
Features & Applications
- Often used for Weight Limit Restricted jobs.
- Rivet cutting and Removal, Pin Driving, and Cleaning Concrete Ready Mix Trucks.
- “PG” Style Handle, Outside Trigger, Hardened Alloy Steel Cylinder.
- Uses Jumbo 11X Tool Steel.
- Replaceable Upper and Lower Sleeves and Bumpers.
- Uses convenient Retainer Lock Springs
- Air Requirement: Approximately 42–46 cfm at 90 psi.
Model & part-number identification
American Pneumatic APT 133 (M133CN) Rivet Buster
Old Part No. 18757, New Part No. 1280583339 (Jumbo 11X Shank)
Complete tool: 133 PG HandleTool part # 1280583339
Pistol grip; Outside trigger; 8-inch stroke; Jumbo 11X tool steel
Your BEST price is just a call away.
Adds the complete tool shown above—not an individual replacement part. Add more tools to build one quote request, then review your quote list.
1-800-241-9669
Need help with a model or part? Talk to Mining Auger & Tool Works.
Technical Specs
| Specification | 133 PG Handle |
|---|---|
| Model | 133 PG Handle |
| Manufacturer model | M133CN |
| Current tool part number | 1280583339 |
| Old tool part number | 18757 |
| Handle | Pistol grip |
| Trigger | Outside trigger |
| Stroke (in.) | 8 |
| Bore (in.) | 1-3/16 |
| Tool steel | Jumbo 11X |
| Air consumption at 90 PSI (CFM) | 42-46 |
| Air inlet | 1/2 inch NPT female |
Complete tool configurations
Match the model, shank and part number. These are complete tools, not replacement parts.
| Model | Shank / Details | Part Number | Quote |
|---|---|---|---|
| 133 PG Handle | Pistol grip; Outside trigger; 8-inch stroke; Jumbo 11X tool steel | 1280583339 |
Accessory Tools
Match the shank, collar and size to your tool. Each button adds that individual accessory to your quote list.
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)10" | jb-10rc |
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)8" | jb-p03-8 |
| Under-collar length (inches)12" | jb-p03-12 |
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)12" | jb-12p |
| Under-collar length (inches)18" | jb-18p |
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)12" | jb-12c |
| Under-collar length (inches)18" | jb-18c |
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)10" | jb-rip |
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)15" | jb-15wc |
Longer lengths available for most tools. Call 800-241-9669 for help matching your tool.
