American Pneumatic
133 T Handle Rivet Buster
Overview
APT 133-T is a 36lb, 8” Stroke, “T” Handle, Top Trigger Demolition Hammer.
The 133-T is an Extremely Powerful Handheld Hammer producing nearly as much Breaking Energy as a 60lb Hammer.
This tool is Excellent primarily for Vertical Hammering due to “Paving Breaker” Style. Its light weight and ease of handling make it frequently used on Parking Ramps, Bridge Decks, Road Work, and all around concrete breaking. Additionally, with the correct accessory tools it is used for Driving Pins and more.
Features & Applications
- Concrete Demolition on Bridge Decks, Parking Ramps, Road Construction and more. T-handle layout for the required working position.
- T-style Handle with Top Trigger.
- Case Hardened Alloy Steel Cylinder.
- Uses Jumbo 11X Tool Steel.
- Replaceable Upper and Lower Sleeves and Bumpers.
- Uses convenient Retainer Lock Springs
- Air Requirement: Approximately 42–46 cfm at 90 psi.
Model & part-number identification
American Pneumatic APT 133 (M133CN) “T” Rivet Buster
Old Part No. 19444, New Part No. 1280174101 (Jumbo 11X Shank)
Complete tool: 133 T HandleTool part # 1280174101
Extended T handle; Top trigger (outside lever); 8-inch stroke; Jumbo 11X tool steel
Your BEST price is just a call away.
Adds the complete tool shown above—not an individual replacement part. Add more tools to build one quote request, then review your quote list.
1-800-241-9669
Need help with a model or part? Talk to Mining Auger & Tool Works.
Technical Specs
| Specification | 133 T Handle |
|---|---|
| Model | 133 T Handle |
| Manufacturer model | M133CNT |
| Current tool part number | 1280174101 |
| Old tool part number | 19444 |
| Handle | Extended T handle |
| Trigger | Top trigger (outside lever) |
| Stroke (in.) | 8 |
| Bore (in.) | 1-3/16 |
| Tool steel | Jumbo 11X |
| Air consumption at 90 PSI (CFM) | 42-46 |
| Weight (lb) | 36 |
| Length (in.) | 32 |
Complete tool configurations
Match the model, shank and part number. These are complete tools, not replacement parts.
| Model | Shank / Details | Part Number | Quote |
|---|---|---|---|
| 133 T Handle | Extended T handle; Top trigger (outside lever); 8-inch stroke; Jumbo 11X tool steel | 1280174101 |
Accessory Tools
Match the shank, collar and size to your tool. Each button adds that individual accessory to your quote list.
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)10" | jb-10rc |
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)8" | jb-p03-8 |
| Under-collar length (inches)12" | jb-p03-12 |
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)12" | jb-12p |
| Under-collar length (inches)18" | jb-18p |
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)12" | jb-12c |
| Under-collar length (inches)18" | jb-18c |
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)10" | jb-rip |
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)15" | jb-15wc |
Longer lengths available for most tools. Call 800-241-9669 for help matching your tool.
