Chicago Pneumatic CP0066NS Pneumatic Scabbler/Scaler with Non-Sparking Pistons
Manufacturer family illustration used on the CP0066 NS product page.
Overview
Chicago Pneumatic CP0066NS is the three-piston scabbler variant with cobalt-tipped pistons. Keep its material and part number separate from the standard CP0066 configuration.
Features & Applications
- Replaceable pistons; intended for cleaning/roughening concrete and construction joints and producing textured finishesSource
CP0066NS Part Numbers
Chicago Pneumatic CP0066NS Pneumatic Scabbler/Scaler
CP0066NS · Part No. 9753288000
CP0066NSSource
Match the model, chuck and complete-tool part number. Compare the configurations below when requesting a quote.
Choose Your Complete Tool
Match the model, chuck and complete-tool part number. Add the configuration you need to your quote list.
| Model | Configuration | Part Number | Quote |
|---|---|---|---|
| CP0066NS | CP0066NS | 9753288000Source |
Technical Specs
| Specification | CP0066NS9753288000 |
|---|---|
| Weight (lb) | 10Source |
| Length (in) | 11Source |
| Height with pistons extended (in) | 5Source |
| Width (in) | 2Source |
| Impact rate (bpm per piston) | 3000Source |
| Piston stroke (in) | 1Source |
| Number / type of pistons | Three 4-point cobalt-tipped pistonsSource |
| Air consumption (cfm at 90 psi) | 27.5Source |
| Air inlet | 3/8 in NPTSource |
The official scabbler datasheet identifies replacement piston 9753288080 (CPNS 066) for CP0066NS, complete-tool part 9753288000. Match the tool identity before ordering service parts.
Product Questions
How many pistons does this scabbler have?
CP0066 NS has three pistons. The manufacturer’s US table specifies 3,000 blows per minute per piston.Source
What distinguishes CP0066NS from CP0066?
CP0066 NS uses cobalt-tipped pistons and carries the manufacturer’s non-sparking designation. CP0066 uses carbide-tipped pistons. The designation alone does not establish hazardous-atmosphere certification.Source
Manuals & Parts Diagrams
- CP0066NS — official manufacturer scabbler datasheet (PDF)Scabblers datasheet, printed p12; revision not stated — Exact CP0066NS complete tool 9753288000 and replacement CPNS 066 piston 9753288080. Describes three 4-point cobalt-tipped pistons. This is a technical datasheet, not an NS exploded parts diagram or operating manual.
For replacement parts, match the tool model, complete-tool part number and serial number to the manufacturer catalogue.
Chicago Pneumatic parts and document lookup
Need help finding a drawing? Send us the model, complete-tool part number and serial number from the tool label.
Manufacturer References
- Chicago Pneumatic — Scabblers — PDF page 1, printed page 12; complete-tool model table, All Models air-consumption/inlet headingEdition / file metadata: Current manufacturer-linked, undatedManufacturer publication
- CP 0066 — manufacturer image reference — Family product image; not a stroke/chuck-specific identification photograph
