- Part Number
- 5540-H
- Stroke
- 3″
- Blows/min
- 1,650
- Weight
- 18 lb
- Air use
- 33–35 CFM
- Overall length
- 14 9/16″
Airrex®
Viper ZE-SeriesChipping Hammer
with Standard Solid Retainer. (SSR)
Overview
This is the Best Chipping Hammer available! A hard hitting and extremely tough tool. It's low breakdown record is superb! Great for general work including ramp and bridge decks, foundry and all around light demo.
Features & Applications
- Available with a 3″ stroke.
- Chuck options: or .
- Standard Solid Retainer (SSR) for oval-collar accessory tools.
Viper ZE-Series Part Numbers
Airrex Viper ZE-Series Chipping Hammer
Viper ZE-3 · 3″ stroke · Part No. 5540-H .580″ Hex × Oval Collar
These references identify the models for the selected chuck. Compare the configurations below, and confirm the model, chuck and retainer when requesting a quote.
Step 1
Select Chuck Size:
Showing .580″ Hex × Oval Collar models and matching accessories.
Ready to Order? Call NowStep 2
Select Stroke:
| Select Your Hammer | |
|---|---|
| Part Number | 5540-H |
| Stroke | 3″ |
| Blows per minute | 1,650 |
| Weight | 18 lb |
| Air consumption | 33–35 CFM |
| Overall length | 14 9/16″ |
| Bore | 1⅛″ |
| Air pressure | 90 PSI |
| Chuck | .580″ Hex |
3″ stroke model
.580″ Hex × Oval Collar
1⅛″ bore • 90 PSI
Selected: Viper ZE-3 (Hex) · 5540-H · SSR.580″ Hex × Oval Collar
Your Quote
0 items · 0 pieces
Add a hammer or accessory to get started.
Step 3
Select Points, Chisels, Etc
The following Points, Chisels, etc. are for use with Standard Solid Retainers.
.580″ Hex × Oval Collar
Longer Lengths, Additional Blades AvailableCall 1-800-241-9669
Moil Point
Standard Lengths: 12″ / 18″ / 24″
.580″ Hex × Oval Collar
Length Under CollarQuantity
12″OCHS-12P
18″OCHS-18P
24″OCHS-24P
Request Longer Lengths
Narrow Chisel
Standard Lengths: 12″ / 18″ / 24″
.580″ Hex × Oval Collar
Length Under CollarQuantity
12″OCHS-12C
18″OCHS-18C
24″OCHS-24C
Request Longer Lengths
2″ Wide Blade Chisel
Standard Lengths: 12″ / 18″ / 24″
.580″ Hex × Oval Collar
Length Under CollarQuantity
12″OCHS-12C2
18″OCHS-18C2
24″OCHS-24C2
Request Longer Lengths
3″ Wide Blade Chisel
Standard Lengths: 12″ / 18″ / 24″
.580″ Hex × Oval Collar
Length Under CollarQuantity
12″OCHS-12C3
18″OCHS-18C3
24″OCHS-24C3
Request Longer Lengths
4½″ Clay Spade
Standard Lengths: 10″
.580″ Hex × Oval Collar
Length Under CollarQuantity
10″OCHS-CS
All-Steel Bushing Tool
Standard Lengths: 8″
.580″ Hex × Oval Collar
Length Under CollarQuantity
8″OCHS-BT
Pin Driver
.580″ Hex × Oval Collar
Request the Size You Need.
Tell us your Pin Diameter, Length, and Chuck Configuration.
Other Retainer Options
Round-collar tools require a compatible optional retainer. The Standard Solid Retainer shown above uses oval-collar tools.
View round-collar points and chisels → · Compare retainer and collar styles →
Longer Lengths, Additional Blades AvailableCall 1-800-241-9669
