Ingersoll Rand
K SeriesChipping Hammer
Features & Applications
- Grooved barrel, lock spring retainer
- Swan neck handle
- Outside trigger
- Time tested valve durability
- Replaceable piston
K Series Part Numbers
K2LA1-Hex · 1-3/4″ stroke · Part No. K2LA1
.580″ Hex
K2LA2-Round · 1-3/4″ stroke · Part No. K2LA2
.680″ Round
Confirm the model, chuck, collar and retainer when requesting a quote.
Need help? 1-800-241-9669
Step 1
Select Chuck Size:
Step 2
Hammer Specifications
K Series hammer specifications| Your Hammer | 1¾″K2LA1-Hex.580″ Hex Shank |
|---|
| Part Number | K2LA1 |
|---|
| Stroke (inches) | 1.75 |
|---|
| Chuck/Shank Size (inches) | .580 Hex |
|---|
| Vibration level 3 axes (ISO 20643) (m/sec²) | 18.0 uncertainty: 5.6 |
|---|
| Retainer Type | None |
|---|
| Blows/Min. [/sec.] | 3600 [60] |
|---|
| Bore (inches) | 0.88 |
|---|
| Air Consumption @ Load cfm (L/min) | 18 (510) |
|---|
| Air Inlet NPT (inch) | 1/4 |
|---|
| Min Hose Size I.D. (inch) | 1/2 |
|---|
| Weight (lbs.) | 6.0 |
|---|
| Length w/o accy (inches) | 10.88 |
|---|
1¾″K2LA1-Hex.580″ Hex Shank - Part Number
- K2LA1
- Stroke (inches)
- 1.75
- Chuck/Shank Size (inches)
- .580 Hex
- Vibration level 3 axes (ISO 20643) (m/sec²)
- 18.0 uncertainty: 5.6
- Retainer Type
- None
- Blows/Min. [/sec.]
- 3600 [60]
- Bore (inches)
- 0.88
- Air Consumption @ Load cfm (L/min)
- 18 (510)
- Air Inlet NPT (inch)
- 1/4
- Min Hose Size I.D. (inch)
- 1/2
- Weight (lbs.)
- 6.0
- Length w/o accy (inches)
- 10.88
K Series hammer specifications| Your Hammer | 1¾″K2LA2-Round.680″ Round Shank |
|---|
| Part Number | K2LA2 |
|---|
| Stroke (inches) | 1.75 |
|---|
| Chuck/Shank Size (inches) | .680 Rnd |
|---|
| Vibration level 3 axes (ISO 20643) (m/sec²) | 18.0 uncertainty: 5.6 |
|---|
| Retainer Type | None |
|---|
| Blows/Min. [/sec.] | 3600 [60] |
|---|
| Bore (inches) | 0.88 |
|---|
| Air Consumption @ Load cfm (L/min) | 18 (510) |
|---|
| Air Inlet NPT (inch) | 1/4 |
|---|
| Min Hose Size I.D. (inch) | 1/2 |
|---|
| Weight (lbs.) | 6.0 |
|---|
| Length w/o accy (inches) | 10.88 |
|---|
1¾″K2LA2-Round.680″ Round Shank
- Part Number
- K2LA2
- Stroke (inches)
- 1.75
- Chuck/Shank Size (inches)
- .680 Rnd
- Vibration level 3 axes (ISO 20643) (m/sec²)
- 18.0 uncertainty: 5.6
- Retainer Type
- None
- Blows/Min. [/sec.]
- 3600 [60]
- Bore (inches)
- 0.88
- Air Consumption @ Load cfm (L/min)
- 18 (510)
- Air Inlet NPT (inch)
- 1/4
- Min Hose Size I.D. (inch)
- 1/2
- Weight (lbs.)
- 6.0
- Length w/o accy (inches)
- 10.88
Selected: K2LA1-Hex · K2LA1.580″ HexNone
Your Quote
0 items · 0 pieces
Add a hammer or accessory to get started.
Step 3
Select Points, Chisels, Etc
The following Points, Chisels, etc. are used with Standard Solid Retainers.
The following Points, Chisels, etc. are for use with Compatible Round-Collar Retainers.
.580″ Hex × Oval Collar
Match the collar and retainer on your hammer.
Compare retainer and collar styles →
Moil Point
.580″ Hex × Oval Collar
Standard Lengths: 12″ / 18″ / 24″
Length Under CollarQuantity
Request Longer Lengths
Narrow Chisel
.580″ Hex × Oval Collar
Standard Lengths: 12″ / 18″ / 24″
Length Under CollarQuantity
Request Longer Lengths
2″ Wide Blade Chisel
.580″ Hex × Oval Collar
Standard Lengths: 12″ / 18″ / 24″
Length Under CollarQuantity
Request Longer Lengths
3″ Wide Blade Chisel
.580″ Hex × Oval Collar
Standard Lengths: 12″ / 18″ / 24″
Length Under CollarQuantity
Request Longer Lengths
4½″ Clay Spade
.580″ Hex × Oval Collar
Standard Lengths: 10″
Length Under CollarQuantity
All-Steel Bushing Tool
.580″ Hex × Oval Collar
Standard Lengths: 8″
Length Under CollarQuantity
Pin Driver
.580″ Hex × Oval Collar
Request the Size You Need.
Tell us your Pin Diameter, Length, and Chuck Configuration.
