- Part Number
- AA0S
- Piston Stroke
- 1-13/16" (45mm)
- Shank Size
- .680" Round Shank or .580" Hex Shank with Round or Oval Collar (Please Specify)
- Piston Diameter
- 7/8" (22.2mm)
- Impact Rate
- 3,000 - 3,200 BPM
- Weight
- 7.9 lbs (3.6kg)
- Overall Length
- 12-3/4" (374.65mm)
- Air Consumption
- 22.95 CFM
- Air Inlet Thread
- 3/8" NPT
- Hose Size
- 1/2" (12.7mm)
- Maximum Air Pressure
- 90 PSI
TAMCO
AA0SChipping Hammer
Overview
Manufactured by Toku and offered through TAMCO.
A compact, lightweight chipping hammer for tight spaces and small enclosures.
Choose .580-inch hex or .680-inch round shank, with round or oval collar; specify both when requesting a quote. The catalog also spells this model AAOS and AA-0S.
AA0S Part Numbers
AA0S · 1-13/16″ stroke · Part No. AA0S
Confirm the model, chuck, collar and retainer when requesting a quote.
Step 1
Select Chuck Size:
Specify Collar for Your Hammer
These models are offered with either shank and collar. Your quote request includes your selection so we can confirm the complete configuration.
Selected shank: .580″ Hex. Match the collar and actual retainer before ordering.
Ready to Order? Call NowStep 2
Select Stroke:
| Select Your Hammer | |
|---|---|
| Part Number | AA0S |
| Piston Stroke | 1-13/16" (45mm) |
| Shank Size | .680" Round Shank or .580" Hex Shank with Round or Oval Collar (Please Specify) |
| Piston Diameter | 7/8" (22.2mm) |
| Impact Rate | 3,000 - 3,200 BPM |
| Weight | 7.9 lbs (3.6kg) |
| Overall Length | 12-3/4" (374.65mm) |
| Air Consumption | 22.95 CFM |
| Air Inlet Thread | 3/8" NPT |
| Hose Size | 1/2" (12.7mm) |
| Maximum Air Pressure | 90 PSI |
Selected: AA0S · AA0S.580″ Hex × Oval CollarSpecify oval or round collar; confirm matching retainer
Your Quote
0 items · 0 pieces
Add a hammer or accessory to get started.
Step 3
Select Points, Chisels, Etc
The following Points, Chisels, etc. are used with Standard Solid Retainers.
The following Points, Chisels, etc. are for use with Compatible Round-Collar Retainers.
.580″ Hex × Oval Collar
Match the collar and retainer on your hammer.
Longer Lengths, Additional Blades AvailableCall 1-800-241-9669
Moil Point
.580″ Hex × Oval Collar
Standard Lengths: 12″ / 18″ / 24″
Length Under CollarQuantity
12″OCHS-12P
18″OCHS-18P
24″OCHS-24P
Request Longer Lengths
Narrow Chisel
.580″ Hex × Oval Collar
Standard Lengths: 12″ / 18″ / 24″
Length Under CollarQuantity
12″OCHS-12C
18″OCHS-18C
24″OCHS-24C
Request Longer Lengths
2″ Wide Blade Chisel
.580″ Hex × Oval Collar
Standard Lengths: 12″ / 18″ / 24″
Length Under CollarQuantity
12″OCHS-12C2
18″OCHS-18C2
24″OCHS-24C2
Request Longer Lengths
3″ Wide Blade Chisel
.580″ Hex × Oval Collar
Standard Lengths: 12″ / 18″ / 24″
Length Under CollarQuantity
12″OCHS-12C3
18″OCHS-18C3
24″OCHS-24C3
Request Longer Lengths
4½″ Clay Spade
.580″ Hex × Oval Collar
Standard Lengths: 10″
Length Under CollarQuantity
10″OCHS-CS
All-Steel Bushing Tool
.580″ Hex × Oval Collar
Standard Lengths: 8″
Length Under CollarQuantity
8″OCHS-BT
Pin Driver
.580″ Hex × Oval Collar
Request the Size You Need.
Tell us your Pin Diameter, Length, and Chuck Configuration.
Longer Lengths, Additional Blades AvailableCall 1-800-241-9669
