- Part Number
- AA0S
- Piston Stroke
- 1-13/16" (45mm)
- Shank Size
- .680" Round Shank or .580" Hex Shank with Round or Oval Collar (Please Specify)
- Piston Diameter
- 7/8" (22.2mm)
- Impact Rate
- 3,000 - 3,200 BPM
- Weight
- 7.9 lbs (3.6kg)
- Overall Length
- 12-3/4" (374.65mm)
- Air Consumption
- 22.95 CFM
- Air Inlet Thread
- 3/8" NPT
- Hose Size
- 1/2" (12.7mm)
- Maximum Air Pressure
- 90 PSI
TAMCO
AA0S Chipping Hammer
Overview
Manufactured by Toku and offered through TAMCO.
A compact, lightweight chipping hammer for tight spaces and small enclosures.
Choose .580-inch hex or .680-inch round shank, with round or oval collar; specify both when requesting a quote. The catalog also spells this model AAOS and AA-0S.
AA0S Part Numbers
AA0S · 1-13/16″ stroke · Part No. AA0S
Confirm the model, chuck, collar and retainer when requesting a quote.
Supplied byJackHammers.com
Step 1
Select Chuck Size:
Specify Collar for Your Hammer
These models are offered with either shank and collar. Your quote request includes your selection so we can confirm the complete configuration.
You Selected.580″ Hex
Match the collar and actual retainer before ordering.Hex or Round
Step 2
Select Stroke:
| Select Your Hammer | |
|---|---|
| Part Number | AA0S |
| Piston Stroke | 1-13/16" (45mm) |
| Shank Size | .680" Round Shank or .580" Hex Shank with Round or Oval Collar (Please Specify) |
| Piston Diameter | 7/8" (22.2mm) |
| Impact Rate | 3,000 - 3,200 BPM |
| Weight | 7.9 lbs (3.6kg) |
| Overall Length | 12-3/4" (374.65mm) |
| Air Consumption | 22.95 CFM |
| Air Inlet Thread | 3/8" NPT |
| Hose Size | 1/2" (12.7mm) |
| Maximum Air Pressure | 90 PSI |
You Selected
AA0SPart # AA0S.580″ Hex × Oval CollarRetainer: Specify oval or round collar; confirm matching retainerConfiguration requires confirmation.
Your Quote
0 items · 0 pieces
Add a hammer or accessory to get started.
Step 3
Select Points, Chisels, Etc
The following Points, Chisels, etc. are used with Standard Solid Retainers.
The following Points, Chisels, etc. are for use with Compatible Round-Collar Retainers.
.580″ Hex × Oval Collar
Match the collar and retainer on your hammer.
Longer Lengths, Additional Blades AvailableCall 1-800-241-9669
Moil Point
.580″ Hex × Oval Collar
Standard Lengths: 12″ / 18″ / 24″
Length Under CollarQuantity
12″OCHS-12P
18″OCHS-18P
24″OCHS-24P
Request Longer Lengths
Narrow Chisel
.580″ Hex × Oval Collar
Standard Lengths: 12″ / 18″ / 24″
Length Under CollarQuantity
12″OCHS-12C
18″OCHS-18C
24″OCHS-24C
Request Longer Lengths
2″ Wide Blade Chisel
.580″ Hex × Oval Collar
Standard Lengths: 12″ / 18″ / 24″
Length Under CollarQuantity
12″OCHS-12C2
18″OCHS-18C2
24″OCHS-24C2
Request Longer Lengths
3″ Wide Blade Chisel
.580″ Hex × Oval Collar
Standard Lengths: 12″ / 18″ / 24″
Length Under CollarQuantity
12″OCHS-12C3
18″OCHS-18C3
24″OCHS-24C3
Request Longer Lengths
4½″ Clay Spade
.580″ Hex × Oval Collar
Standard Lengths: 10″
Length Under CollarQuantity
10″OCHS-CS
All-Steel Bushing Tool
.580″ Hex × Oval Collar
Standard Lengths: 8″
Length Under CollarQuantity
8″OCHS-BT
Pin Driver
.580″ Hex × Oval Collar
Request the Size You Need.
Tell us your Pin Diameter, Length, and Chuck Configuration.
Longer Lengths, Additional Blades AvailableCall 1-800-241-9669
